808nm 600W Macro Channel Diode Laser Array for Hair removal, Skin rejuvenation and other aesthetic applications.
WV10 808nm-600W Macro Channel Diode Laser Array
PRODUCT PARAMETERS
| Optical Parameters | |
| Part Number | R808±15-Q600-WV10-10×12-001 |
| Center Wavelength λc（nm） | 808 |
| Wavelength Tolerance δλc（nm） | ±15 |
| Output Power（W） | 600 |
| Number of Bars | 12 |
| Bar-to-Bar Pitch（mm） | 2.18 |
| Spot Size（mm） | 10 X 24.00 |
| Fast Axis Full Divergence Angle（FWHM）（°） | 78 |
| Slow Axis Full Divergence Angle（FWHM）（°） | 20 |
| Wavelength Temperature Coefficient（nm/℃） | ~ 0.3 |
| Electrical Parameters | |
| Operating Current Iop（A） | ≤50 |
| Threshold Current Ith（A） | ≤10 |
| Operating Voltage Vop（V） | ≤24 |
| Slope Efficiency per Bar （W/A） | ≥1.1 |
| Power Conversion Efficiency（%） | ≥48 |
| Duty Cycle（max., %） | 40 |
| Pulse Width（max., ms）1 | 400 |
| Repetition Rate（Hz） | 1 ~ 10 |
| Cooling Parameters | |
| Cooling Water Requirements | Deionized Water or Distilled Water |
| Water Temperature（℃）2 | 20 ~ 30 |
| Water Pressure（Mpa） | 0.25 ~ 0.35 |
| Water Flow Rate（L/min）3 | 3.5 ~ 4.5 |
Notes：
1. Since the duty cycle of the module cannot exceed 40% during operation, when the maximum pulse width is 400ms, the repetition frequency can only be 1Hz; when the maximum repetition frequency is 10Hz, the maximum pulse width is 40ms only.
2. Avoid laser operation in condensing environments, ensure ambient temperature exceeds minimum safe operating limits.
3. The water flow rate refers to the flow of cooling water exiting the laser system.
4. Custom wavelengths available upon request.
5. All the data in the above table are the typical values obtained from the tests at room temperature of 25℃, and the final data is subject to the final test report.
APPLICATION
-
Hair removal
- Skin rejuvenation
KEY FEATURES
-
808nm operating wavelength
/ - 50W single bar/
- AuSn soldering/
- Macro channel water cooling/
-
High power density
/ - High efficiency/
- High reliability and stability/
- Customizable multi-wavelength solutions/
