Articulated Arm & Handpieces for Q-Switched Lasers

1. Product Overview
RealLight Technology launches dedicated 7-joint articulated arms and matching treatment handpieces for HQF series flashlamp-pumped Q-switched solid-state lasers. Customized for 1064 nm & 532 nm laser systems, this beam delivery solution addresses common drawbacks of generic light guides, including severe energy loss, beam drift, lens contamination and stiff movement. Equipped with fully sealed optical cavity and precision multi-joint mechanics, it delivers steady and efficient laser transmission for aesthetic clinics, optical research labs and precision industrial machining. The design guarantees consistent laser output and safe operation, significantly improving equipment performance and end-user satisfaction.

2. Core Product Advantages
2.1 Fully Sealed Dust-Proof Optical Path for Long-Term Stable Output
The totally enclosed beam channel blocks dust, aerosols and workshop contaminants from adhering to reflective mirrors, preventing beam distortion and energy degradation over time. It greatly reduces disassembly cleaning frequency and after-sales maintenance cost, suitable for beauty salons, laboratories and industrial workshops with harsh ambient conditions.

2.2 Smooth 7-Joint Mechanism with Ultra-Precise Beam Positioning
Balanced 7-joint structure enables jitter-free 360° rotation and stable free positioning. High-precision reflective optics limit spot adjustment tolerance within ±0.5 mm, ensuring zero beam offset at any operating angle and reducing operator fatigue during long-duration procedures.

2.3 Multi-Wavelength Compatibility with Transmission Efficiency Over 85%
Compatible with 1064 nm therapeutic infrared laser, 532 nm frequency-doubled green laser and 650 nm aiming beam. The maximum clear aperture reaches φ16 mm with a total optical path length of 1677.5 mm, achieving overall transmittance above 85% to retain original pulse energy for tattoo removal, LIBS excitation, laser shock peening and other high-energy applications.

2.4 Lightweight Aviation Aluminum Frame with Customizable Colors
Constructed from 6061 aviation aluminum alloy, the complete arm weighs only 10.5 kg with balanced weight distribution for effortless handheld operation. Multiple housing colors are customizable to match OEM equipment branding requirements.

3. Wide Application Scenarios
3.1 Biomedical & Aesthetic Medicine (Primary Application)
Standard beam delivery accessory for Q-switched cosmetic laser systems, widely used for all types of tattoo removal, freckle, melasma and age spot treatment, as well as skin rejuvenation and epidermal ablation. Uniform and stable beam minimizes thermal skin damage, shortens single treatment time and optimizes clinical outcomes.

3.2 Optical Research & Analytical Detection
Ideal for Laser-Induced Breakdown Spectroscopy (LIBS), laser-induced fluorescence, Raman spectroscopy, differential absorption lidar, laser ranging, particle image velocimetry and laser ultrasonic testing. Stable long-path beam ensures repeatable spectral and detection data.

3.3 Industrial Laser Machining
Applied to precision microfabrication and laser shock peening. Flexible multi-joint design allows multi-angle alignment on complex workpieces, maintaining consistent beam quality for uniform mass production results.

4. Product Summary
RealLight 7-joint articulated arms and matched handpieces are original supporting beam delivery components for all HQF flashlamp-pumped Q-switched lasers. Featuring fully sealed dust-proof optical path, low-drift high-precision optics, smooth seven-joint movement and over 85% transmittance, it eliminates typical defects of conventional light guides such as energy attenuation, easy contamination and inflexible operation. One single product covers aesthetic, research and industrial fields with durable lightweight structure and customizable appearance, serving as the standard preferred matching solution for OEM integration and equipment upgrade.
